I’ve written before about the discipline side of this device — verifying my shielded box, trusting measurements over firmware claims. This post is the other half: the actual techniques I put through it. One open-source ESP32 handheld, with Wi-Fi, Bluetooth, several 2.4 GHz radios, a sub-GHz radio, and an IR transceiver, is basically a portable wireless-security lab. Here’s what I tested on each band and what I learned.

First, the law, because it’s the frame for everything below. In the UK, receiving and scanning is fine. Transmitting on many of these features is restricted under the Computer Misuse Act and the Wireless Telegraphy Act, and RF jamming is illegal to operate outright — no “own device” exemption. Everything transmit-side here was against my own equipment, on battery, in a controlled setup. Do not do the TX half of this list on anything you don’t own.

Wi-Fi

• Monitor mode + packet capture. Put the radio in promiscuous mode, hop the channels, and write real .pcap files to the SD card — thousands of management, data, and beacon frames in a sweep, opening cleanly in Wireshark afterwards. This is the foundation of all Wi-Fi analysis, and it’s the defensive skill: you can’t understand an attack you can’t see on the wire.
• Deauthentication detection. The device flags deauth and disassociation frames in the air. Interesting real-world result: a quiet sweep at home still turned up dozens of deauth/disassoc frames — almost certainly my own access points doing band-steering and kicking weak clients, not an attack. Which is the whole lesson of a detector: it tells you frames are flying; you have to work out whether it’s hostile or just your network being normal.
• Beacon spam / SoftAP / injection. These are the transmit-side Wi-Fi features — flooding fake network names, standing up a rogue access point, injecting raw frames. On this particular unit I proved (with an independent listening adapter) that the Wi-Fi transmit path was actually dead despite the firmware reporting success — a good reminder that “the tool says it worked” is never proof.
• A regulatory gotcha worth knowing: the chip defaults to a region that only scans channels 1–11, so it silently misses the channels 12–13 that are legal and used in the UK. If you survey Wi-Fi with a device like this and don’t fix the country setting, you have a blind spot and won’t know it.

Bluetooth Low Energy

• BLE scanning and sniffing — enumerate nearby devices, watch advertisements.
• BLE advertisement spam (the “Sour Apple”-style flood of fake device popups) transmitted and was caught two ways: on a phone, and independently by a separate monitoring device. The genuinely useful part was the detection fingerprint: the flood showed up as dozens of brand-new random MAC addresses, each appearing for one to four packets and then vanishing forever — whereas real devices advertise steadily and accumulate packets over time. Even the randomiser wasn’t uniform; the addresses clustered in a way that’s itself a tell. That’s the defender’s takeaway: this attack is noisy and has a recognisable signature.

Sub-GHz (the 433 MHz world)

This is the band of garage remotes, cheap doorbells, weather sensors, and a lot of “IoT” that predates anyone thinking about security. The device can capture and replay sub-GHz signals. The lesson here is sobering: an enormous amount of real-world kit uses static codes with no rolling security, meaning a captured signal replayed verbatim just works. Testing this on my own remotes is the fastest way to understand why fixed-code RF is a bad idea and why rolling-code matters.

2.4 GHz spectrum + the jamming research

• Spectrum analysis. The 2.4 GHz radios can scan the band channel by channel and show you what’s busy — you can literally see your own Wi-Fi and Bluetooth occupying the spectrum. This is also how I discovered my “shielded” enclosure wasn’t shielding anything: the in-box spectrum looked identical to the open room.
• Jamming — researched, contained, and mostly a lesson in containment. In a controlled bench test a narrowband interferer parked on a victim channel drove 100% packet loss on a test link; a broadband sweep was far less effective per target (it only sits on any one channel briefly). But the headline finding was the safety one: because my enclosure gave no real attenuation, I stopped short of trusting any powered run as “contained.” Jamming is illegal to operate in the open in the UK, full stop, and this is exactly why proving your containment comes before the interesting part.

Infrared

The IR transceiver does capture-and-replay of remote-control codes — the TV-B-Gone class of trick. Lower stakes, same principle as sub-GHz: a lot of everyday signals are unauthenticated and trivially repeatable.

What the whole exercise taught me

Cheap, capable RF hardware is here and anyone can buy it. That’s the real security message. But the value of owning one isn’t the “attacks” — half of which are illegal to actually transmit and several of which didn’t even work on my unit. The value is that every offensive feature has a defensive mirror: deauth detection, BLE-spam fingerprinting, understanding why static sub-GHz codes and non-PMF Wi-Fi are weak. You learn to defend a band by watching how it breaks — in your own lab, within the law, trusting measurements over marketing.

Tech: ESP32-S3, nRF24L01 ×3, CC1101 sub-GHz, 802.11 monitor mode + PCAP, BLE, IR, and a lot of reading of the Wireless Telegraphy Act.
